| Model | APoE-2405 |
| Output Voltage | 24V |
| Output Current | 500mA |
| Input Voltage | 90~264Vac Maximum |
| Input Frequency | 47~63Hz |
| Input Current | 0.3A Maximum |
| nrush Current | 30A Maximum |
| Ripple | 240mV Maximum |
| Hold-Up Time | 10ms |
| Over Current Protection | Auto Recovery |
| MTRF | 50,000H(at 25°C) |
| Short-circuit Protection | Auto Recovery |
| Operating Temperature | 0~40°C |
| Storage Temperature | -20~+85°C |
| Relative Humidity | 5%-90% |
| Safety | CE / FCC |
RJ45 Output(Data & Power)
| Pin | Symbol | Description |
| 1 | Rx+ | Data Receive |
| 2 | Rx- | Data Receive |
| 3 | Tx+ | Data Transmit |
| 4 | -Vdc_ | return(+) Feeding Power(+) |
| 5 | -Vdc_ | return(+) Feeding Power(+) |
| 6 | Tx- | Data Transmit |
| 7 | -Vdc | Feeding Power(-) |
| 8 | -Vdc | Feeding Power(-) |
