General Specification
Cable Length | 50M |
Input | Power : DC Jack Data:Rj45 |
Output | Rj45 Data + Power |
PIN define | Data: 1,2,3,6 Power:(+)4,5/7,8 |
Input Voltage | 5~57VDC |
Ethernet Cable Specification
Description | Cat.5e UTP 26AWG/4P |
Cable Outer | UV Protected |
Conductor Resistance | <148.94Ω/km |
Insulation Resistance | >100MΩ/km |
Dielectric-Withstand Test | 500VAC/min |
Spark Test | 1500VAC |
